Basic Info

Model No.: 1GQN-90

Application Field: Agriculture

Power Source: Tractor

Arbor Configuration: Horizontal Axis

Certification: SGS, ECE, EU, CE

Type: Rotary Tiller

Machinery Type: Soil Preparation Machinery

Drive Type: Gear Drive

Working Efficiency: High Efficiency

MOQ: 1sets

Packing: Iron Cage

Usage: Farm Cultivate

Color: Green

Application: Agricultural Cultivator

Advantage: Flexible Operation

Feature: Match Tractor

Name: Agricultural Equipment Rotavator

Key Word: Gearbox Rotary Tiller

Additional Info

Packaging: Strong exporting standard packages. Iron frame ( As your requirements )

Productivity: 1000 set/sets per month

Brand: TIANDE

Transportation: Ocean,Land,Air

Place of Origin: China (Mainland)

Supply Ability: 1000 set/sets per month

Certificate: CE/ISO/SGS

Port: Qingdao,Ningbo,Shanghai

Product Description

Power tillage machine small tractor rotavators tiller:

The power tillage machine small tractor rotavators tiller is equipped with a small gearbox and a large modulus high-strength gear, which makes the PTO output of the tractor and the power input of the rotary tiller horizontal, which greatly prolongs the service life of the universal shaft. The new integrated suspension makes the whole machine more securely hooked, and the new bearing housing improves sealing performance. This series of cultivators rotary tiller can be equipped with special deep-cultivating knives and extended rotary cultivators. Under effective conditions, the rotary tiller mini rotavator working depth is 8~18 cm, which is the ideal choice for your higher requirements for soil preparing.

Parameters of power tillage rotavators tiller:

1. Model: 1GQN-90

2. Dimension: 960X1070X980 mm

3. Weight: 210 kg

4. Matched Tractor: ≥18 hp

5. Working depth: 8~18 cm

6. Working width: 90 cm

7. Qty of rotary blade: 18

8. Gear speed ratio: 13/30  13/27  14/26  15/20  15/23

9. Linkage: Three-point mounted

Features of power tillage rotavators tiller:

1. Standard 3 point suspension is suitable for all kinds of power tractors.

2. Thickened ball iron gearbox. Use the new integrated suspension to make machine hang more firmly.

3. The rotavator can replaceable multi-form cutter shaft.

4. The gearbox has four holes in the front and rear, and adopt anti-receding bolt to fix.

5. The rotary tiller has new type bearing block and especial deep rotary blades.

6. Rotary tiller machines working deep: 8--18cm.

7. Enhance gearbox and inside with big modulus high strength gear, make tractors PTO output and the rotary cultivator in level state,  greatly extend the service life of the universal drive shaft.

8. The rotary tiller can equip with special deep tillage knife shaft and lengthened rotary tillage knife .
