Basic Info

Model No.: 1S-160

Application Field: Agriculture

Power Source: Tractor

Machinery Type: Arable Machinery

Traction Type: Hanging

Arbor Configuration: Horizontal Axis

Certification: SGS, ECE, EU, CE

Operation: Continuous Running Operation

Working Efficiency: High Efficiency

MOQ: 1sets

Application: Agricultural Cultivator

Advantage: Flexible Operation

Feature: Match Tractor

Drive Type: Match Tractor

Color: Customized

Name: Sub-soiling Machine

Packing: Iron Frame Package

Usage: Loosening Soil

Additional Info

Packaging: Strong exporting standard packages. Iron frame ( As your requirements )

Productivity: 1000 set/sets per month

Brand: TIANDE

Transportation: Ocean,Land,Air

Place of Origin: China (Mainland)

Supply Ability: 1000 set/sets per month

Certificate: CE/ISO/SGS

Port: Qingdao,Ningbo,Shanghai

Product Description

Farm deep subsoiler:

The deep loose shovel adopts the special curved inverted trapezoidal design, which does not intermingle the soil layer during operation, and does not turn over the soil. After loosening the soil, the surface is smooth, maintaining the integrity of the vegetation. After heavy-duty roller presses to suppress the soil and improve the preservation effect, the soil loss can be minimized, which is more conducive to no-tillage sowing.

The high-gap reinforcement shovel seat and the three-row beam frame structure can be applied to soils with different textures and a large amount of straw covering to avoid clogging and improve the passability of the implement. The single shovel can adjust the line spacing within 20 cm. According to the supporting power, there are also three kinds of deep shovel, small, medium and large, with a working depth of 25-50 cm.

Parameters of farm deep subsoiler:

1. Model: 1S-160

2. Dimension: 1800×2000×1330

3. Matched Tractor: 50~90 hp

4. Working depth: 25~50 cm

5. Working width: 160 cm

6. Shovel space: 80 cm

7. Working efficiency: 1.2~1.4 hm2/h

8. Linkage: Three-point mounted

Features of farm deep subsoiler:

1. Multi-cambered surface subsoiling shovel, break plow sole, only loosening soil all around, but not turning over. Working depth can reach to 25~65 cm.

2. Rainy season: enhance soil water storage and waterlodding capability.

3. Dry season: ground flate, vegetation coverage well, upper real lower virtual, improve drought resistance capability.

4. Increase soil permeability, make the root systerm more developed and increase production income.

5. Three bean frame design is easy to adjust line spacing.

6. Widening frame design is to prevent congestion and improve the crossing efficiency.

7. Novel mud scraping plate combination is to ensure the quality of repression.

8. Corrugated suppression roller.
